zenon Energy Edition: IEC 61850 and IEC 60870; IEC 61400-25



As a worldwide accepted standard, the transfer protocol IEC 61850 from the International Electrotechnical Commission (IEC) provides generally applicable provisions for communication between devices in medium voltage and high voltage electrical switching equipment and also defines the system requirements necessary for it. Thanks to the driver developed in-house by our specialists, zenon users can configure their SCADA projects without problems using IEC 61850, provided that they are aware that there are clear differences in command processing between IEC 61850 and IEC 60870:

Differences between IEC 61850 and IEC 60870

Whereas under IEC 60870, the selection of the command mode in zenon is configured by means of parameters, this is carried out in IEC 61850 by means of the control model of the logical node and then at protocol level. Also, the command and response variables are defined differently. Under IEC 60870, they are defined by selecting the type ID (numerically); with IEC 61850 the addressing is displayed in an object model (symbolically).

IEC 61400-25

For communication, supervisory and control of wind power plants COPA-DATA provides an IEC 61400-25 driver. The mapping complies with Part 4, Appendix C (MMS) of the standard. The driver represents the client-side and can be configured via SCL data import.
